济南卷帘门:如何调节卷帘门限位?

来源:http://www.jnzxmy.com 日期:2024-05-17 发布人:

  卷帘门的限位开关有两个,一个是上限位,有一个是下限位,能够控制开关的开启和关闭,调节的时候有两个人来操作,一个人要在上边调节转动杠杆的位置,另外一个人需要调节卷帘门的上下。具体操作的时候,将上面的一个卡片拨动到适合的度数,能够脱离螺母或者松开上面的螺钉。将门将卷帘门调到合适的位置之后,再将螺母压住开关上的滚轮,能够听到咔嚓的一声,也就是卡片已经卡入到相应的槽中,这时候就可以将螺钉拧紧。如果位置不合适,还可以再进行调整,直到的位置为止。

  There are two limit switches for the roller shutter door, one is the upper limit and the other is the lower limit, which can control the opening and closing of the switch. When adjusting, it is best to have two people to operate. One person needs to adjust the position of the rotating lever on the upper side, and the other person needs to adjust the up and down of the roller shutter door. When performing specific operations, move one of the cards on top to the appropriate degree to detach the nut or loosen the screw on top. After adjusting the roller shutter door to the appropriate position, press the nut onto the roller on the switch. A click can be heard, indicating that the card has been inserted into the corresponding slot. At this point, the screw can be tightened. If the position is not suitable, further adjustments can be made until the optimal position is reached.

  使用电动卷闸门需要注意哪些方面?

  What should be noted when using electric roller gates?

  1、使用之前,应该详细观察一下电动卷闸门的门扇或者是门轨是否有出现变形卡住等现象,还应该观察一下控制盒是否有安装牢固,是否有电流外露出来。若有发现问题的话,则需要及时进行处理,当故障解决以后,才可以使用电动卷闸门。


  1. Before use, it is necessary to carefully observe whether the door leaf or door rail of the electric rolling gate is deformed or stuck, and also observe whether the control box is securely installed and whether there is any exposed current. If any problems are found, they need to be dealt with in a timely manner. Only after the fault is resolved can the electric roller shutter be used.

  2、当电动卷闸门上升或者是下降的时候,使用者不可以随意离开现场,应该仔细观察电动卷闸门的开启或者是关闭时的运行状态,若有听到异常响声或者是门扇出现运行不稳的现象的话,则需要及时安装停止按钮,并且需要及时把电源切断掉,然后让维修人士上门帮忙进行检测和维修,当故障解决以后,才可以继续使用电动卷闸门。

  2. When the electric roller shutter rises or falls, the user must not leave the site at will. They should carefully observe the operating status of the electric roller shutter when it is opened or closed. If there is any abnormal noise or unstable operation of the door leaf, a stop button should be installed in a timely manner, and the power should be cut off in a timely manner. Then, professional maintenance personnel should come to the site for inspection and maintenance. Only after the fault is solved can the electric roller shutter be continued to be used.

  3、当电动卷闸门上升或者是下降的时候,还应该仔细观察一下电动卷闸门的相关限位装置是否可以自动停止,若不可以的话,则应该手动进行停止,当限位装置被调整好以后,才可以继续使用和操作。。

  3. When the electric roller shutter rises or falls, it is also necessary to carefully observe whether the relevant limit devices of the electric roller shutter can automatically stop. If not, it should be manually stopped. Only after the limit devices are adjusted can they continue to be used and operated..

  以上就是有关:济南卷帘门  的介绍,想了解更多的内容请点击:http://www.jnzxmy.com 我们将会全心全意为您提供满分服务,欢迎您的来电!
